LBC LRO-1G6 SINGLE RACK OVEN NATURAL GAS

Description

Brand new, crated and ready for installation or shipment from our warehouse in Burnsville, MN.

New and used racks available, as well.

Construction Features:

● Heavy-duty stainless steel interior and exterior

● Cooking compartment insulated with 5” high-temp insulation

● Automatic, heavy-duty “B” style lift and gear-driven rotation system

● Heavy-duty door with 16” x 57.5” double pane viewing window

● Interior door safety release mechanism

● Oven accommodates one single rack

● Reversible Door Swing

Performance Features:

● Energy Star Certification

● 100-525 deg F temperature range

● Linear counterflow heat exchanger

● Burner manifold uses inshot burners with hot surface igniter

● High volume, waterfall steam system

● Three-point, air circulation system with adjustable shutters

● Self adjusting clutch protects operator and prevents damage

● Rack drive automatically stops, lifts and lowers with door operation

● Racks load at floor level (no ramp)

● Patent 10,314,315

Integrated Hood Features and Performance:

● Meets the construction requirements of NFPA 96 & UMC for Type I & II Hoods (fire system, if required, shall be by others)

● Fully integrated hood with single point exhaust connection

● 20 ga fully welded stainless steel body construction

● 8” round collar, 1525 fpm @ 530 cfm, 1.0” w.c. (roof top ventilator not included)

● 12 sqft hood capture area. Filter Velocity = 120 fpm @ 0.3” w.c. and 530 cfm

Integrated UL Listed Hood (Optional):

● Listed to UL 710 for heavy duty operation up to 525°F

○ See separate spec sheet for UL 710 ventilation requirements

Control Features:

● Digital Display Control (Standard):

○ Two control modes with programmable features > Single-step cooking mode: » 40 programmable recipes with 6 quick select buttons > 6-step cooking mode: » 30 programmable recipes

○ Programmable features: Steam, Vent, Blower Delay and Pulse Air ○ Selectable Automatic Temperature Setback

● Manual Backup Control (Standard):

○ Manually control heat and blower, lights and rotation, and steam
